- Operating Temp: -20°c to max.+90°C
- Nominal voltage: 1100 V
- Test voltage: 3000 V
- Insulation resistance: Min. 20 MΩ x km
- Min. bending radius: 7 x cable diameter
- Flame propagation: Flame retardant test as per IEC 60332-1
Information
Generally confirming to DIN VDE 0250, IEC 60332-1, Generally to AS/NZS 5000:2003, CE Directive 72/23/EEC
Conductor:
EC copper class 5 and class 6 generally conforms to IEC 60228, DIN VDE 0281
Insulation:
XLPE
Colour:
Flexible Nitrile rubber (NBR) Orange, Black, Red, Blue Jacket
*Any other Color on specific request can also be supplied
- Heat resistant insulation
- High insulation resistance
- Excellent flexibility to last longer in flex applications
- High resistance to cuts, tears & abrasion
- Better mechanical & electrical properties
- Resistance to oil, solvents and chemicals
- Excellent ozone and weather resistant
XLPE/NBR 0.6/1kV 90°C
For applications where extreme flexibility is required – high current capacity. Power – Switchboards, flexible droppers from bus bars, transformers, load banks or other equipment requiring fixed or flexible wiring. Pumping – Suitable for permanent submersion
Standard length cable packing:
Coils 100, 200,300 and 500 m in wooden reels
