XLPE Unarmoured Cables

Copper conductor, XLPE insulated, un-armoured cables, Cable Code 2XY

Information

Technical Data
  • Operating Temp: -20°c to max.+90°C
  • Nominal voltage: 1100 V
  • Test voltage: 3000 V
  • Insulation resistance: Min. 10 MΩ x km
  • Min. bending radius: Single core: 15 X Overall diameter, Multi core: 12 X Overall diameter
  • Flame propagation: Flame retardant test as per IEC 60332-1
Cable Structure

generally conforms to IS 7098-1, BS 5467, IEC 60502-1, BS 7889

Conductor:
Material – Copper / Aluminium solid or stranded wires class 1 or 2 according to IEC 60228,IS 8130

Insulation:
XLPE-Cross linked polyethylene compound

Inner Sheath:
PVC

Outer Sheath:
PVC TYPE ST-2 OF IS 5831

Application

XLPE Unarmoured Cables
Power cables for energy supply are installed outdoors, in underground, in water, indoors, in cable ducts, power stations, for industry and distribution boards as well as in subscriber networks, where mechanical damages are not to be expected.

Standard length cable packing:
Coils 100, 200, 300, 500, 1000 m. in wooden reels

Cable Design

Color Coding: AS IS 1554 ( Indian Standard )Color coding: AS IEC 60502 Part-1, B.S. 6346
Color Coding: AS IS 1554 ( Indian Standard )
Single core 2 Core 3 Core 4 Core 5 Core
Red or Black Red, Black Red, Yellow, Blue Red, Yellow, Blue, Black Red, Yellow, Blue, Black, Grey
Color coding: AS IEC 60502 Part-1, B.S. 6346
Single core 2 Core 3 Core 4 Core 5 Core
Black or Yellow/Green Blue and Brown or Yellow-Green and Black Brown, Black, Grey or Yellow/Green, Blue, Brown Blue, Brown, Black, Grey or Yellow/Green, Brown, Black, Grey Blue, Brown, Black, Grey, Black or Yellow/Green, Blue, Brown, Black, Grey
