H05VV-F, H05V2V2-F

Normal / Heat resistant PVC Flexible multicore cable

Information

Technical Data
  • Operating Temp: H05VV-F : -20°c to +80°C, H05V2V2-F : -20°c to +90°C
  • Nominal voltage: H05VV-F : 300/500 V, H05V2V2-F : 300/500 V
  • Test voltage: H05VV-F : 2.5KV, H05V2V2-F : 2.5KV
  • Insulation resistance: Min. 20 MΩ x km
  • Min. bending radius: 7 x cable diameter
Cable Structure

Conductor:
Fine Stranded Copper (Class 5 – Flexible Plain Copper) to VDE 0295 IEC 60228

Insulation / Sheath:
HO5VVF : PVC
HO5V2V2F : Heat Resistant PVC

Colour:
White, Black, Blue or as per party order

Cable features
  • Special heat resistant insulation
  • High current carrying capacity
  • Less heat energy radiation
  • Longer flex life
  • High compatibility of cores
  • Excellent resistant to moisture, abrasion, grace, oil
  • Excellent mechanical & electrical properties
  • Insulation is highly thermal stable
  • Harmonized acc. to European standards
  • Tested by SGS, EIL, RITES, NPC
Application

H05VV-F, H05V2V2-F
H05VV-F AND H05V2V2-F cordage is a flexible PVC insulated, PVC jacketed harmonized cord recommended for use in electronic and electrical equipment such as office.

Standard length cable packing:
100, 200, 500, 1000 m. in reels

Technical DataTable

H05VV-F (300/500 V)H05V2V2-F (300/500 V)
H05VV-F (300/500 V)
Nominal cross sectional area of conductor Nominal insulation thickness Nominal sheath thickness in mm Max overall diameter in mm Max conductor resistance at 20°C Min insulation resistance at 70°C
2 core 3 core 4 core 5 core 2 core 3 core 4 core 5 core
Lower limit Upper limit Lower limit Upper limit Lower limit Upper limit Lower limit Upper limit
sqmm mm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm Ω/km MΩkm
0.75 0.6 0.8 0.8 0.8 0.9 5.7 7.2 6 7.6 6.6 8.3 7.4 9.3 26 0.011
1 0.6 0.8 0.8 0.9 0.9 5.9 7.5 6.3 8 7.1 9 7.8 9.8 19.5 0.01
1.5 0.7 0.8 0.9 1 1.1 6.8 8.6 7.4 9.4 8.4 10.5 9.3 11.6 13.3 0.01
2.5 0.8 1 1 1.1 1.2 8.4 10.6 9.2 11.4 10.1 12.5 11.2 13.9 7.98 0.0095
4 0.8 1.1 1.2 1.2 1.4 9.7 12.1 10.5 13.1 11.5 14.3 13 16.1 4.95 0.0078
  • All are class 5 flexible conductor
  • Insulation grade is TI2
  • Sheathing grade is TM2
Cores colour: Core Identification
2 Core 3 Core 4 Core 5 Core
Blue & Brown Green-and-Yellow, Blue, Brown Green-and-Yellow, Brown, Black, Grey or Green-and-Yellow, Blue, Brown, Black Green-and-Yellow, Blue, Brown, Black and Grey
H05V2V2-F (300/500 V)
Nominal cross sectional area of conductor Nominal insulation thickness Nominal sheath thickness in mm Max overall diameter in mm Max conductor resistance at 20°C Min insulation resistance at 90°C
2 core 3 core 4 core 5 core 2 core 3 core 4 core 5 core
Lower limit Upper limit Lower limit Upper limit Lower limit Upper limit Lower limit Upper limit
sqmm mm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm sqmm Ω/km MΩkm
0.75 0.6 0.8 0.8 0.8 0.9 5.7 7.2 6 7.6 6.6 8.3 7.4 9.3 26 0.011
1 0.6 0.8 0.8 0.9 0.9 5.9 7.5 6.3 8 7.1 9 7.8 9.8 19.5 0.01
1.5 0.7 0.8 0.9 1 1.1 6.8 8.6 7.4 9.4 8.4 10.5 9.3 11.6 13.3 0.01
2.5 0.8 1 1 1.1 1.2 8.4 10.6 9.2 11.4 10.1 12.5 11.2 13.9 7.98 0.0095
4 0.8 1.1 1.2 1.2 1.4 9.7 12.1 10.5 13.1 11.5 14.3 13 16.1 4.95 0.0078
  • All are class 5 flexible conductor
  • Insulation grade is TI3
  • Sheathing grade is TM3
Cores colour: Core Identification
2 Core 3 Core 4 Core 5 Core
Blue & Brown Green-and-Yellow, Blue, Brown Green-and-Yellow, Brown, Black, Grey or Green-and-Yellow, Blue, Brown, Black Green-and-Yellow, Blue, Brown, Black and Grey
