- Operating Temp: -40°c to max.+110°C
- Nominal voltage: 1100 V
- Test voltage: 3000 V
- Insulation resistance: Min. 10 MΩ x km
- Min. bending radius: 6 x cable diameter
- Flame propagation: Flame retardant test as per IEC 60332-1
Information
Generally confirming to IEC 60228, IEC60502-1, AS/NZ500:2003 & AS/NZS60079, CE Directive 72/23/EEC
Conductor:
EC copper class 5 and class 6 generally conforms to IEC 60228, DIN VDE 0281
Insulation:
EPR
Sheath:
Flexible Nitrile rubber (NBR) Orange, Black, Red, Blue Jacket
*Any other Color on specific request can also be supplied
- Ultra high performance flexible for longer life and added safety
- High elasticity & high temperature resistant
- Outstanding toughness & durability
- High resistance to cuts, tears & abrasion
- Resistance to oil, solvents and chemicals
- Excellent ozone and weather resistant
EPR/NBR 0.6/1Kv 110°C
For applications where extreme flexibility is required – high current capacity. Power – Switchboards, flexible droppers from bus bars, transformers, load banks or other equipment requiring fixed or flexible wiring. Pumping – Suitable for permanent submersion
Standard length cable packing:
Coils 100, 200,300 and 500 m. in wooden reels
