400 PVC speaker cable, multicore, round

400 PVC speaker cable, round

Information

Application

All products of the 400 LOUDSPEAKER series impress with their extremely high flexibility. 0,15 stranded wires and a very soft PVC outer sheath make this possible. These cables are particularly used in mobile applications on stages, in studios or in the conference industry.

Technical DataTable

DataTable 1
Part no. Cable structure Conductor
resistance

Ohm / km

Outer diameter

approx. mm

Cop.
weight

kg / km

Weight

approx. kg / km

400089 2×1,5 < 12,7 6,6 28,8 73,4
400090 2×2,5 < 7,9 7,5 48,0 106,9
400091 2×4,0 < 4,9 9,4 76,8 163,7
400092 4×2,5 < 7,9 8,8 96,0 169,3
400093 4×4,0 < 4,9 11,6 153,6 272,4
400060 8×2,5 < 7,9 13,5 192,0 349,0
>400094 8×4,0 < 4,9 16,8 307,2 541,6
